Camera Specification:
| Sensor | 1/3 CMOS CCD | 1/3 CMOS CCD | 1/4 PC7070 CMOS | 1/3 PC3089 CMOS |
| Resolution: | N:510×492 pixels P: 500×582 pixels | N:752×494 pixels P: 752×582 pixels | N:976×494 pixels P: 1020×508 pixels | 756(H) x 504(V) |
| TV line | 520-600TVL | 650-700TVL | / | / |
| Lens: | 1.7mm | 1.7mm | 1.7mm | 1.7mm |
| Min illumination: | 0Lux (LED ON) | 0Lux (LED ON) | 0Lux (LED ON) | 0Lux (LED ON) |
| IR led: | 6pcs | 6pcs | 6pcs | 6pcs |
| Night Vision distance: | 10m | 10m | 10m | 10m |
| Waterproof | IP68 | IP68 | IP68 | IP68 |
| View angle: | 170°/120° | 170°/120° | 170°/120° | 170°/120° |
| Power voltage: | 12V | 12V | 12V | 12V |
| Operation Temp.: | -20°C~+70°C | -20°C~+70°C | -20°C~+70°C | -20°C~+70°C |
